06 Downlights Fixed LED > The COB Downlight Range Die Cast
10110CA/W/W
10W LED recessed downlight, IP20. Ideal for general lighting applications.
Complete with 300mA driver.
Complies with standard EN60598-1 and any other specific standards.
Complete with 300mA driver.
Complies with standard EN60598-1 and any other specific standards.
Dimensions
Downloads
Physical Specification
Item Group
06 Downlights Fixed LED
Family
The COB Downlight Range Die Cast
Order Code
10110CA/W/W
Colour
White
Material
Die Cast
Shape
Circular
Height
65mm
Diameter
120mm
Cutout Hole Diameter
95mm
Recessed Ceiling
Yes
Depth Required
100mm
Indoor
Yes
Adjustable
No
Electrical Characteristics
Gear
External-Included
Fitting + Driver
Input Voltage
220-240V
50 Hz
Yes
60 Hz
Yes
Safety Class
Power (Watts)
10W
IP Rating
IP20
Light Source
LED built in
Dimmable
No
F Mark
Fitting
Input Type
Constant Current
Input Current
300mA
Voltage
30V
Safety Class
Power (Watts)
9W
IP Rating
IP20
Light Source
LED built in
LED Type
COB
LED Brand
Epistar
F Mark
Gear
Gear Type
Led Driver
Input Voltage
220-240V
50 Hz
Yes
60 Hz
Yes
Power (Watts)
7,5-12,6W
Power Factor
0,9
Constant Current
Yes
300mA
25-42V
IP Rating
IP20
Safety Class
Dimmable
No
Ambient Temp
45°C
Operating Temp
85°C
Housing Material
Plastic
Output Terminal
Cable
Illumination Data
Colour Temperature
3000K
Lumen Output
850lm
Light Efficiency
85lm/W
CRI
90
Beam Angle
60°
Illumination Diagram
Packing Info
Box Length
13,5cm
Box Width
7,5cm
Box Height
13,5cm
Box Weight
0.392kg
Pcs/Carton
50
Barcode
5291889051978
HS Code
9405413990
Energy Label
Certification & Warranty
Warranty
2 years
Average Lifetime
30000hrs
Wee Directive
Yes
Year in which the CE mark was affixed
17
