14 Plafo > Decorative Plafo
62135NA/W/W
35W LED Decorative Plafo, IP20, suitable for residential and
commercial application.
Supplied with non-dimmable LED driver.
Complies with standard EN60598-1 and any other specific standards.
Supplied with non-dimmable LED driver.
Complies with standard EN60598-1 and any other specific standards.
Dimensions
Downloads
Physical Specification
Item Group
14 Plafo
Family
Decorative Plafo
Order Code
62135NA/W/W
Colour
White
Material
Aluminium
Shape
Rectangular
Length
450mm
Width
450mm
Height
125mm
Surface Ceiling
Yes
Indoor
Yes
Adjustable
No
Electrical Characteristics
Gear
External-Included
Fitting + Driver
Input Voltage
220-240V
50 Hz
Yes
60 Hz
Yes
Safety Class
Power (Watts)
35W
IP Rating
IP20
Light Source
LED built in
Dimmable
No
F Mark
Fitting
Input Type
Constant Current
Input Current
700mA
Voltage
48V
Power (Watts)
33,6W
IP Rating
IP40
Light Source
LED built in
LED Type
SMD 2835
LED Brand
Epistar
F Mark
Gear
Gear Type
Led Driver
Input Voltage
220-240V
50 Hz
Yes
60 Hz
Yes
Power (Watts)
14-37,8W
Power Factor
0,9
Constant Current
Yes
700mA
20-54V
IP Rating
IP20
Safety Class
Dimmable
No
Housing Material
Plastic
Output Terminal
Cable
Illumination Data
Colour Temperature
3000K
Lumen Output
2100lm
Light Efficiency
60lm/W
CRI
80
Illumination Diagram
Packing Info
Box Weight
4.100kg
Pcs/Carton
1
Barcode
5291889046783
HS Code
9405413990
Energy Label
Certification & Warranty
Warranty
3 years
Wee Directive
Yes
Year in which the CE mark was affixed
18
