13 Wall & Ceiling LED > The Roof tile Range
67512/AN/W
8W Wall light, IP65.
Complete with 200mA driver.
Complies with standard EN60598-1 and any other specific standards.
Complete with 200mA driver.
Complies with standard EN60598-1 and any other specific standards.
Dimensions
Downloads
Physical Specification
Item Group
13 Wall & Ceiling LED
Family
The Roof tile Range
Order Code
67512/AN/W
Colour
Anthracite
Material
ABS
Diffuser Material
PC
Shape
Rectangular
Length
110mm
Width
50mm
Height
220mm
Surface Wall
Yes
Indoor
Yes
Outdoor
Yes
Adjustable
No
Electrical Characteristics
Gear
Built In
Fitting + Driver
Input Voltage
220-240V
50 Hz
Yes
60 Hz
Yes
Safety Class
Power (Watts)
8W
IP Rating
IP65
Light Source
LED built in
Dimmable
No
F Mark
Fitting
Input Type
Constant Current
Input Current
200mA
Voltage
33,5V
Power (Watts)
6,7W
IP Rating
IP65
Light Source
LED built in
LED Type
SMD 2835
LED Brand
Epistar
Gear
Gear Type
Led Driver
Input Voltage
220-240V
50 Hz
Yes
60 Hz
Yes
Power (Watts)
5,6-8,4W
Power Factor
0,9
Constant Current
Yes
200mA
28-42V
IP Rating
IP20
Safety Class
Dimmable
No
Ambient Temp
0
Operating Temp
0
Housing Material
Plastic
Illumination Data
Colour Temperature
3000K
Lumen Output
400lm
Light Efficiency
50lm/W
CRI
80
Illumination Diagram
Packing Info
Box Length
23cm
Box Width
12,5cm
Box Height
6cm
Box Weight
0.500kg
Pcs/Carton
20
Barcode
5291889068921
HS Code
9405114090
Energy Label
Certification & Warranty
Warranty
2 years
Wee Directive
Yes
Year in which the CE mark was affixed
20
