08 Strips & Profiles > The High Power Strips 24V
7885/W
Flexible LED light strip, with SMD2835 LEDs, 294LEDs/meter, 48W/meter.Supplied in 2 meters roll with white PCB and double adhesive tape for a better fixing.
Can be cut every 7,14cm (21-LED segment).
Requires 24V DC constant voltage LED driver.
Complies with standard EN60598-1 and any other specific standards.
Can be cut every 7,14cm (21-LED segment).
Requires 24V DC constant voltage LED driver.
Complies with standard EN60598-1 and any other specific standards.









Dimensions

Downloads
Physical Specification
Item Group
08 Strips & Profiles
Family
The High Power Strips 24V
Order Code
7885/W
Shape
Rectangular
Length
2000mm
Width
39mm
Surface Ceiling
Yes
Surface Wall
Yes
Surface Floor/Ground
Yes
Indoor
Yes
Electrical Characteristics
Gear
Order Separately
Fitting
Input Type
Constant Voltage
Input Voltage
24V DC
Safety Class

Power (Watts)
48W/m
IP Rating
IP20
Light Source
LED built in
LED Type
SMD 2835
LED Brand
Refond
LED Number
294LEDs/m
F Mark

Illumination Data
Colour Temperature
3000K
Lumen Output
4400lm/m
Light Efficiency
91,67lm/W
CRI
90
Illumination Diagram

Packing Info
Box Length
16cm
Box Width
14,5cm
Box Height
5cm
Box Weight
0.240kg
Pcs/Carton
20
Barcode
5291889046233
HS Code
9405499090
Energy Label

Energy Class

Certification & Warranty
Warranty
5 years
Wee Directive
Yes
Year in which the CE mark was affixed
13
