04 Recessed Spots Adjustable LED > The 1W/2W Mini Series Aluminium
11103B/W/W
1W/2W COB LED adjustable recessed spot IP20.
Requires 350mA/700mA driver.
Complies with standard EN60598-1 and any other specific standards.
Requires 350mA/700mA driver.
Complies with standard EN60598-1 and any other specific standards.
Dimensions
Downloads
Physical Specification
Item Group
04 Recessed Spots Adjustable LED
Family
The 1W/2W Mini Series Aluminium
Order Code
11103B/W/W
Colour
White
Material
Aluminium
Shape
Circular
Height
36mm
Diameter
52mm
Cutout Hole Diameter
45mm
Recessed Ceiling
Yes
Depth Required
60mm
Indoor
Yes
Adjustable
1 Direction
Electrical Characteristics
Gear
Order Separately
Fitting
Input Type
Constant Current
Input Current
350mA/700mA
Safety Class
Power (Watts)
1W/2W
IP Rating
IP20
Light Source
LED built in
LED Type
COB
LED Brand
Bridgelux
LED Number
1
Cable Length
40cm
Fast Connector
One Light 350+700
F Mark
Illumination Data
Colour Temperature
3000K
Lumen Output
200lm@700mA
Light Efficiency
100lm/W
CRI
90
Beam Angle
40°
Illumination Diagram
Packing Info
Box Length
9cm
Box Width
6cm
Box Height
5,5cm
Box Weight
0.089kg
Pcs/Carton
100
Barcode
5291889042464
HS Code
9405413990
Energy Label
Certification & Warranty
Warranty
5 years
Wee Directive
Yes
Year in which the CE mark was affixed
15
