24 Control & Dimming > Infrared Motion Sensors
22006
230V 400W (LED) 800W (Incandescent) Recessed Ceiling Infrared Motion Sensor.
Hold time and daylight sensor are adjustable via dip switches
Complies with standard EN60669 and any other specific standards.
Hold time and daylight sensor are adjustable via dip switches
Complies with standard EN60669 and any other specific standards.
Dimensions
Downloads
Physical Specification
Item Group
24 Control & Dimming
Family
Infrared Motion Sensors
Order Code
22006
Material
Plastic
Shape
Rectangular
Length
80mm
Width
70mm
Height
55mm
Recessed Ceiling
Yes
Indoor
Yes
Outdoor
Yes
Electrical Characteristics
Sensor
Input Voltage
220-240V
Power (Watts)
400W (LED) 800W (Incandescent)
Safety Class
Motion
Yes
Brightness
Yes
Detection Angle
180°
Detection Distance
12m
Time Delay
10sec ± 3sec to 15min 2 min (adjustable)
Installation height
1,8-2,5m
Packing Info
Box Length
8,5cm
Box Width
6cm
Box Height
8,5cm
Box Weight
0.140kg
Pcs/Carton
50
Carton Length
45cm
Carton Width
35cm
Carton Height
19cm
Carton Weight
6,9Kg
Barcode
5291889056720
HS Code
8536309090
Certification & Warranty
Warranty
2 years
Wee Directive
Yes
Year in which the CE mark was affixed
18
