13 Wall & Ceiling LED > Dark Light Cylinders Tubes
12122D/MG/W
22W COB LED Cylinder CRI 90 with exchangeable reflectors.
Reflector must be order separately.
Complete with non-dimmable LED driver.
Complies with standard EN60598-1 and any other specific standards.
Reflector must be order separately.
Complete with non-dimmable LED driver.
Complies with standard EN60598-1 and any other specific standards.
Dimensions
Downloads
Physical Specification
Item Group
13 Wall & Ceiling LED
Family
Dark Light Cylinders Tubes
Order Code
12122D/MG/W
Colour
Metal Grey
Material
Aluminium
Shape
Circular
Height
100mm
Diameter
100mm
Surface Ceiling
Yes
Indoor
Yes
Adjustable
No
Electrical Characteristics
Gear
Built In
Fitting + Driver
Input Voltage
220-240V
50 Hz
Yes
60 Hz
Yes
Safety Class
Power (Watts)
22W
IP Rating
IP20
Light Source
LED built in
Dimmable
No
F Mark
Fitting
Input Type
Constant Current
Input Current
500mA
Voltage
38,4V
Power (Watts)
19,2W
IP Rating
IP20
Light Source
LED built in
LED Type
COB
LED Brand
Cree
Gear
Gear Type
Led Driver
Input Voltage
220-240V
50 Hz
Yes
60 Hz
Yes
Power (Watts)
13,5-20W
Power Factor
0,9
Constant Current
Yes
500mA
27-40V
IP Rating
IP20
Safety Class
Dimmable
No
Housing Material
Plastic
Illumination Data
Colour Temperature
3000K
Lumen Output
1540lm
Light Efficiency
70lm/W
CRI
90
Beam Angle
24°
Illumination Diagram
Dark Light
Yes
Packing Info
Box Length
10,5cm
Box Width
10,5cm
Box Height
11cm
Box Weight
0.490kg
Pcs/Carton
20
Barcode
5291889071013
HS Code
9405413990
Energy Label
Certification & Warranty
Warranty
5 years
Wee Directive
Yes
Year in which the CE mark was affixed
20
